aesthetics and performance combine

SF52 is our most flexible aluminium curtain wall system, designed to give specifiers a host of aesthetic options for every application, whilst making fabrication incredibly easy. With consistent slim 52mm sightlines and enhanced thermal performance to exceed current building regulations, SF52 is an elegant solution for both ground floor and high rise projects. All configurations have excellent weather performance, being fully CWCT and EN13830 weather tested and are 100% recyclable with a life expectancy of 40+ years.

prod-info-life-cycle prod-info-recycle prod-info-gla-single-double-triple prod-info-weather prod-info-facets

Configuration:Fully Capped

A traditional zone drained, fully capped, aluminium curtain walling system with uniform slim 52mm sightlines.

  • Use in combination with vertically capped, horizontally capped or silicone glazed SF52 curtain wall to create an individual and striking external facade.
  • Choose from a large variety of caps for even more aesthetic possibilities.
  • Create impact both inside and out with either 40 or 60 micron powder coat in any RAL colour or an anodised finish.
Glazing 6mm-50mm
Single, Double, Triple
Facets Up to 6 degrees per mullion
3 degrees per side
Mullion & Transom Sizes 50mm, 80mm, 100mm, 125mm, 150mm, 175mm, 200mm, 225mm, 250mm
Weather Rating CWCT Sequence B and EN13830
600Pa air permeability
600Pa water tightness
2400Pa wind resistance

Zone Drained Fully Capped

The fully capped system can be zone drained via traditional transom pressure plate drainage or spout drainage through the mullion.

Mullion Drained Fully Capped

SF52 is also available as a mullion drained fully capped system.

prod-info-life-cycle prod-info-recycle prod-info-gla-double prod-info-weather prod-info-facets-10

Configuration:Silicone Glazed

A silicone glazed aluminium curtain walling system with uniform slim 52mm sightlines, featuring a specially designed toggle system to allow externally frameless facades.

  • Add ventilation whilst continuing the frameless effect with our fully compatible SMRF frameless vents.
  • Use in combination with fully capped, vertically capped or horizontally capped SF52 curtain wall to create an individual and striking external facade.
Glazing 28mm-40mm
Double
Facets Up to 10 degrees per mullion
5 degrees per side
Mullion & Transom Sizes 50mm, 80mm, 100mm, 125mm, 150mm, 175mm, 200mm, 225mm, 250mm
Weather Rating CWCT Sequence B and EN13830
600Pa air permeability
600Pa water tightness
2400Pa wind resistance

Zone Drained

The silicone glazed SF52 curtain walling system is zone drained by spout drainage through the mullion. This helps to prevent recalls to site due to breakages or splitting in glass to glass joint seals.

prod-info-life-cycle prod-info-recycle prod-info-gla-double prod-info-weather prod-info-facets-10

Configuration:Vertical Capped


A vertically capped aluminium curtain wall system with uniform slim 52mm sightlines, featuring a specially designed toggle system used horizontally to allow externally frameless transoms.

  • Vertical capped sections give an arresting façade and can make the building look taller.
  • Add ventilation whilst continuing the horizontally frameless effect with our fully compatible SMRF frameless vents.
  • Use in combination with fully capped, horizontally capped or silicone glazed SF52 curtain wall to create an individual and striking external facade.
  • Choose from a large variety of caps for even more aesthetic possibilities.
  • Create impact both inside and out with either 40 or 60 micron powder coat in any RAL colour or an anodised finish.
Glazing 28mm-40mm
Double
Facets Up to 10 degrees per mullion
5 degrees per side
Mullion & Transom Sizes 50mm, 80mm, 100mm, 125mm, 150mm, 175mm, 200mm, 225mm, 250mm
Weather Rating CWCT Sequence B and EN13830
600Pa air permeability
600Pa water tightness
2400Pa wind resistance

Zone Drained

The vertically capped SF52 curtain walling system is zone drained by spout drainage through the mullion.

prod-info-life-cycle prod-info-recycle prod-info-gla-double prod-info-weather prod-info-facets

Configuration:Horizontal Capped

A horizontally capped aluminium curtain wall system with uniform slim 52mm sightlines, featuring a specially designed toggle system used vertically to allow externally frameless mullions.

  • Horizontal capped stripes give an arresting façade and can make the building look wider.
  • Add ventilation whilst continuing the horizontally frameless effect with our fully compatible SMRF frameless vents.
  • Use in combination with fully capped, vertically capped or silicone glazed SF52 curtain wall to create an individual and striking external facade.
  • Choose from a large variety of caps for even more aesthetic possibilities.
  • Create impact both inside and out with either 40 or 60 micron powder coat in any RAL colour or an anodised finish.
Glazing 28mm-40mm
Double
Facets Up to 6 degrees per mullion
5 degrees per side
Mullion & Transom Sizes 50mm, 80mm, 100mm, 125mm, 150mm, 175mm, 200mm, 225mm, 250mm
Weather Rating CWCT Sequence B and EN13830
600Pa air permeability
600Pa water tightness
2400Pa wind resistance

Zone Drained

The horizontally capped SF52 curtain walling system is zone drained using traditional transom drainage.

prod-info-life-cycle prod-info-recycle prod-info-gla-double-triple prod-info-weather prod-info-facets-20

Configuration:Mullion Drained

A traditional fully capped mullion drained aluminium, curtain walling system with uniform slim 52mm sightlines. Unlike the zone drained system, it has different mullion and transom profiles and is constructed using lap joints performed using a special Senior punch tool or standard machinery available on the market for easy and faster installation.

  • Choose from a large variety of caps for even more aesthetic possibilities.
  • Create impact both inside and out with either 40 or 60 micron powder coat in any RAL colour or an anodised finish.
Glazing 28mm-52mm
Double, Triple
Facets Up to 20 degrees per mullion
10 degrees per side
Mullion Sizes 72mm, 92mm, 117mm, 142mm, 167mm, 192mm, 217mm, 242mm
Transom Sizes 50mm, 80mm, 100mm, 125mm, 150mm, 175mm, 200mm, 225mm, 250mm
Weather Rating CWCT Sequence B and EN13830
600Pa air permeability
600Pa water tightness
2400Pa wind resistance

Mullion Drained Fully Capped

This fully capped SF52 system is mullion drained using spouts above the splice joints.

prod-info-life-cycle prod-info-recycle prod-info-gla-double-triple

Configuration:Sloped Glazing

A traditional fully capped sloped glazed aluminium system with uniform slim 52mm sightlines.

  • Perfect for creating a sloped screen - can be used to create varied pitches from 15 degrees from horizontal to 15 degrees from vertical
  • Ideal for use as roof glazing in atriums – thermally enhanced system to keep the warmth in and reduce energy loss
  • Gives a seamless finish - integrates with the SF52 Mullion Drained System to create a smooth connection between a sloped screen and a vertical curtain wall
